Design: Style a prototype

Style a Prototype Script

How do we style our prototype? In case you had design confused with aesthetics initially, this is the part where we get graphical. Graphic design tools are great for generating high resolution images and creating our own graphics and icons. Those tools can be used for designing sample screens.

However it's not advisable to design screens with graphic design tools, if there are a lot of screens with recurring elements to design or if it's needed to implement interaction, for example for user testing. In these cases there are a variety of prototyping tools built exclusively for designing screens. There are templates of major guidelines to use elements from and results can typically be used for testing as well.

If we need different colors that match well, there is an easy technique: just select the color you like and keep the hue value like it is. Then, you can play with the saturation and the brightness to create a color that matches the first one. Try it out! There are more aids we can use to create an appealing color scheme. Visit the website link below to learn all you need about colors for designing the user interface.

Thanks for the attention and see you next time!

Using the design language from Task 11, redesign your paper prototype accordingly. The obtained results should have a high graphical fidelity and resemble the goal for your final design. These screens can best be designed using graphical software like the ones presented in Task .

Tools

Tips & tricks for styling your prototype

Look for templates of common UI elements and patterns
Find inspiration looking at other public projects designed with the tool of your choice
Not every detail has to be completely covered - include short texts to explain why option is not yet available

Choosing colors

In web design, the used color scheme is a so-called "additive" one. This means that by combining multiple colors, the resulting color is determined by adding up the wavelengths. This is reflected in the RGB and hex values, which are some of the most commonly used color systems in front-end programming. "RGB" stands for "Red, Green, Blue", those are the colors represented in the pixels on your screen. Each value for the three colors ranges from "0,0,0" (black) to "255,255,255" (white). Sometimes you will see a fourth value, which determines the transparency of the color. The hex color code simply results from transforming the RGB value into a hexadecimal value.

Now, if you intend to pick amazing colors for your web app, it would be a good idea to visualize all colors systematically, e.g. in a color wheel, in order to make an educated decision about which colors to pick. The colors that you can typically see in a wheel like the one below will most likely just vary in their hue.

Here are some approaches to determine appealing color combinations for your visual design:

Monochrome

Easy to find appealing color combination
Try keeping the hue value as it is, increase saturation and decrease brightness.
Example: Qatar Airways

Complementary

Opposite colors elicit high contrast
Elements pop out and can be identified easily
Contrast needs to be used in a meaningful way
Example: Panicstudio TV

Analogous

Nearby colors have low contrast
Good choice for banners and website backgrounds
Example: Clear Todo App

Triadic

Playful color scheme
To keep balance, choose one dominant and two accent colors
Example: Superman logo

Final few tips: If you need inspiration, explore color schemes in images of the physical world or venture out yourself and figure out which colors typically seem to "go together" in your environment or the surroundings your web app will be used in! Also, never forget to check accessibility criteria, e.g. does your font size and color make the text on your app readable enough?
